BRY-NEON-8x16-220V-6500K-NEON LED STRIP - 1

BRY-NEON-8x16-220V-6500K-NEON LED STRIP - 2

BRY-NEON-8x16-220V-6500K-NEON LED STRIP - 3

BRY-NEON-8x16-220V-6500K-NEON LED STRIP

BS02-00013

BRY-NEON-8x16-220V-6500K-NEON LED STRIP - 1

BRY-NEON-8x16-220V-6500K-NEON LED STRIP - 2

BRY-NEON-8x16-220V-6500K-NEON LED STRIP - 3

Family Products

Specifications
Data Sheet

General Characteristics

Model No

BS02-00013

Main Family

LED Strip

Sub Family

220V LED Neon

Type

Strip

Body Color

White

Lamp Shape

Non-Directional

Light Source

LED

Warranty

2 years

Class

Class III

IP

IP65

Product Characteristics

Wattage

6 w/mt

Color Temperature

6500K

Quse Lumen

350 lm/mt

Color Rendering Index (CRI)

>80

Energy Efficiency Level

G

Color Category

Cool White

Electrical Characteristics

Lifetime

20000 h

Voltage

220-240V

Material

FPCB

Working Temperature

-20 C+40 C

Frequency

50-60 Hz

Dimensions & Weight

P. Width

10 mm

Weight

151,5 gr

Package Informations

N.W.

15,15 kgs

G.W.

15,70 kgs

PCS/CTN

100 mt

Length

315 mm

Width

315 mm

Height

270 mm

EAN

5949097728723

BS02-00013 DATASHEET
