BRY-ECOLINE-180L-2835-3000K-220V-IP54-LED STRIP - 1

BRY-ECOLINE-180L-2835-3000K-220V-IP54-LED STRIP - 2

BRY-ECOLINE-180L-2835-3000K-220V-IP54-LED STRIP - 3

BRY-ECOLINE-180L-2835-3000K-220V-IP54-LED STRIP

BS01-00510

BRY-ECOLINE-180L-2835-3000K-220V-IP54-LED STRIP - 1

BRY-ECOLINE-180L-2835-3000K-220V-IP54-LED STRIP - 2

BRY-ECOLINE-180L-2835-3000K-220V-IP54-LED STRIP - 3

Family Products

Specifications
Data Sheet

General Characteristics

Model No

BS01-00510

Main Family

LED Strip

Sub Family

220V LED Strip

Type

Strip

Body Color

White

Lamp Shape

Non-Directional

Light Source

LED

Warranty

2 years

Class

Class III

IP

IP54

Product Characteristics

Wattage

12 w/mt

Color Temperature

3000K

Quse Lumen

1350 lm/mt

Color Rendering Index (CRI)

>80

Energy Efficiency Level

F

Color Category

Warm White

Electrical Characteristics

Lifetime

20000 h

Voltage

220-240V

Material

FPCB

Working Temperature

-20 C+40 C

Frequency

50-60 Hz

Dimensions & Weight

P. Width

16 mm

Weight

129 gr

Package Informations

N.W.

12,90 kgs

G.W.

13,30 kgs

PCS/CTN

100 mt

Length

310 mm

Width

310 mm

Height

225 mm

EAN

5949097724237

BS01-00510 DATASHEET
